-Enhanced ProcessPulsed Tig (Gtaw-P)
-FeaturesWireless Remote Compatible
-IncludesPower Source Only
-Input Frequency50/60 Hz
-Input Voltage110/115/120/208/220/230/240/380/400/460/480V AC
-Maximum Amperage (stick)210A
-Maximum Amperage (tig)210A
-Maximum Input Current15 A @ 208V (Three-Phase), 26 A @ 208V (Single-Phase)
-Minimum Amperage (stick)5A
-Minimum Amperage (tig)1A
-Open Circuit Voltage80V DC
-Overall Depth19 1/2″
-Overall Height13.61″
-Overall Width8.61″
-Phase1, 3
-PolarityDc
-Power Cord Length8 ft.
-ProcessStick Welding, Tig Welding
-Pulse Frequency0.1 pulses/sec. to 500.0 pulses/sec.
-Rated Output @ Duty Cycle (stick)160 A @ 26.4 V, 60%90 A @ 23.6 V, 60%
-Rated Output @ Duty Cycle (tig)210 A @ 18.4 V, 60%, 125 A @ 15 V, 60%
-Remote Connection Type14-Pin (Miller)
-Remote ControlRemote Control Not Included
-Tig Arc Start FeatureLift Arc Start, High Frequency Start
-Weight38 lbs.
-Welding Power Source TypeCc
Local Pickup is available
Layby is also Available
35 Woodward Cres, Miller NSW 2168
Monday to Friday 9am - 5pm
Saturday 9am - 4pm
Sunday 10am - 4pm
$3,499.00
1 in stock
